Jinlang 1P49QMG

Jinlang 1P49QMGThe Jinlang 1P49QMG is a 0.1 l (101.8 cc, 6.21 cu-in) single cylinder, 4-stroke, forced air-cooled internal combustion motorcycle engine, manufactured by Zhejiang Jinlang Power Co. LTD.

It has a 49 mm (1.93 in) cylinder bore and 54 mm (2.13 in) piston stroke, compression ratio rating is 10.5:1. The JL1P49QMG produced 7.1 PS (5.2 kW; 7.0 HP) at 7,700 rpm of maximum horsepower and 7.0 Nm (0.7 kg·m; 5.2 ft·lb) at 6,200 rpm of torque.

General information

Engine Specifications
ModelJinlang 1P49QMG
TypeFour-stroke, single cylinder
Displacement101.8 ml (6.21 cu-in)
Max. horsepower7.1 PS (5.2 KW; 7.0 HP) at 7,700 rpm
Max. torque (crank PTO)7.0 Nm (0.7 kg·m; 5.2 ft·lb) at 6,200 rpm
Cooling systemForced-air
Ignition systemCapacitance discharge ignition (CDI)
Lubricating systemSplash
Starting systemElectric / kick
Fuel usedUnleaded gasoline (octane number 86 or higher)

Dimensions and Weight

JL 1P49QMG
Length, mm (in)680 (26.8)
Width, mm (in)425 (16.7)
Height, mm (in)320 (12.6)
Dry weight, kg (lb)24 (52.9)
