Briggs and Stratton 40G777

Briggs and Stratton 40G777The Briggs and Stratton 40G777 Professional Series is a 656 cc (40.0 cu·in) V-twin air-cooled four-stroke internal combustion gasoline engine, manufactured by Briggs and Stratton.

The B&S 40G777 engine has an OHV (overhead valve) design and a vertical PTO shaft. This engine is equipped with float type carburetor and an electronic ignition system. The B&S 40G777 engine used Dual-Clean air cleaner (paper element with a foam pre-cleaner).

The cylinder bore is 75.44 mm (2.97 in) and the piston stroke is 73.40 mm (2.89 in). This engine produced 20.3 PS (14.9 kW; 20 HP) at 3,600 rpm of horsepower.

The breakdown of the engine code is as follows:

  • 40 – Displacement
  • G – Basic design series
  • 7 – Vertical PTO-shaft
  • 7 – Plain bearing, Pressure lubrication
  • 7 – Electric starter

General information

Engine Specifications
ModelB&S 40G777 Professional Series
Type4-stroke, OHV, V-twin
Displacement656 cm 3 (40.0 cu-in)
Max. horsepower20.3 PS (14.9 kW; 20 HP) at 3,600 rpm
Max. torque
Fuel systemFloat typet carburetor
Cooling systemForced-air
Ignition systemElectronic
Lubricating systemFull pressure lubrication system with spin-on oil filter
Starting systemElectric starter
Fuel usedGasoline
Fuel tank capacity

Cylinder Block and Head

Cylinder block
Bore x Stroke75.44 mm X 73.40 mm (2.97 x 2.89 in)
Number of piston rings (compression / oil):2 / 1
Cylinder Head
Valve Arrangement:OHV
Valves:4 (2 per cylinder)

Service Information

Engine
Max speed3,600 rpm
Valve clearance
Intake valve clearance0.10-0.15 mm (0.004-0.006 in)
Exhaust valve clearance0.10-0.15 mm (0.004-0.006 in)
Oil system
Oil typeAPI SF, SG, SH, SJ or higher
Recommended oil Summer: SAE 30, 10W-30
Winter: SAE 5W-30
Oil capacity (with filter)1.9 liters (2.01 US.qts, 1.67 Imp. qts)
Ignition system
Spark plugChampion RC12YC
Spark plug gap0.7-0.8 mm (0.0276-0.0315 in)
